High Speed Hydraulic Slewing – IWYHG44A Series

Product Description:

High Speed Hydraulic Slewing Drives IWYHG Series are designed for excavator.  They feature high working pressure, good stability, compact configuration, light weight, easy installation and maintenance.  Learn about various this series slewing by saving the data sheet for your interests.




  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    Product Tags

    High Speed Hydraulic Slewing Drives IWYHG are applied to slewing platform drives in a wide spectrum of applications, including construction vehicles, crawler excavators, aerial platforms, and tracked vehicles.

    Mechanical Configuration:

    IWHG44A hydraulic slewing consists of hydraulic motor, multi-stage planetary gearbox, brake and valve block with brake function.   This series slewing can bear hydraulic and external load impact.  The output gear shaft can directly drive the ring gear on the slewing platform. Customized modifications for your device are available at any moment.





    Main Parameters of IWYHG44A Hydraulic Slewing Device:

    Output Torque(N.m)

    Speed(rpm)

    Ratio

    Rated Pressure(Mpa)

    Displacement(ml/r)

    Motor Displacement(ml/r)

    Weight(Kg)

    Excavator Type(Ton)

    4000

    0-100

    18.4

    26

    1192.9

    64.832

    90

    14-16
